Wheatley, 5P-313B, Quintuplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | quintuplex |
| Minimum Plunger Diameter: | ¾" |
| Maximum Plunger Diameter: | 1" |
| Stroke length: | 3⅛" |
| Maximum Working Pressure: | 9,055 PSI |
| Rod/Piston Load: | 4000lb |
| Gallons per Minute: | 26.6 |
| Barrels per Day: | 912 |
| Brake Horse Power: | 88.0 |
- Pump Curves
- Performance Data Table
- Features/benefits not available.
| Pump | English Units | 50 RPM | 200 RPM | 350 RPM | 500 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| 5P-313B | 1.000 | 0.7854 | 1.821 | 0.0531 | 5093 | 91.07 | 2.656 | 364.3 | 10.62 | 637.5 | 18.59 | 910.7 | 26.56 |
| 0.875 | 0.6013 | 1.395 | 0.0407 | 6652 | 69.73 | 2.034 | 278.9 | 8.135 | 488.1 | 14.24 | 697.3 | 20.34 | |
| 0.750 | 0.4418 | 1.025 | 0.0299 | 9054 | 51.23 | 1.494 | 204.9 | 5.977 | 358.6 | 10.46 | 512.3 | 14.94 | |
