Wheatley, HP360-AM (308T-7M), Triplex, Plunger Pump
- 308 horsepower 7" stroke horizontal triplex single acting plunger pump
- Available in three fluid end materials
- Pump speeds up to 265 RPM
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 2¼" |
| Maximum Plunger Diameter: | 3¼" |
| Stroke length: | 7⅛" |
| Maximum Working Pressure: | 3,600 PSI |
| Rod/Piston Load: | 19400lb |
| Gallons per Minute: | 203.4 |
| Barrels per Day: | 6974 |
| Brake Horse Power: | 308.0 |
Mouse-over to Enlarge
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 265 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| HP360-AM 308T-7M | 3.250 | 8.2958 | 26.319 | 0.7676 | 2339 | 1316 | 38.38 | 3948 | 115.1 | 6580 | 191.9 | 6974 | 203.4 |
| 3.125 | 7.6699 | 24.333 | 0.7097 | 2529 | 1217 | 35.49 | 3650 | 106.5 | 6083 | 177.4 | 6448 | 188.1 | |
| 3.000 | 7.0686 | 22.425 | 0.6541 | 2745 | 1121 | 32.7 | 3364 | 98.11 | 5606 | 163.5 | 5943 | 173.3 | |
| 2.875 | 6.4918 | 20.596 | 0.6007 | 2988 | 1030 | 30.04 | 3089 | 90.11 | 5149 | 150.2 | 5458 | 159.2 | |
| 2.750 | 5.9396 | 18.844 | 0.5496 | 3266 | 942.2 | 27.48 | 2827 | 82.44 | 4711 | 137.4 | 4994 | 145.6 | |
| 2.625 | 5.4119 | 17.169 | 0.5008 | 3585 | 858.5 | 25.04 | 2575 | 75.12 | 4292 | 125.2 | 4550 | 132.7 | |
| 2.500 | 4.9087 | 15.573 | 0.4542 | 3952 | 778.7 | 22.71 | 2336 | 68.13 | 3893 | 113.6 | 4127 | 120.4 | |
| 2.375 | 4.4301 | 14.055 | 0.4099 | 4379 | 702.7 | 20.5 | 2108 | 61.49 | 3514 | 102.5 | 3725 | 108.6 | |
| 2.250 | 3.9761 | 12.614 | 0.3679 | 4879 | 630.7 | 18.4 | 1892 | 55.19 | 3154 | 91.98 | 3343 | 97.5 | |
- Cast iron power frame
- Ductile Iron crankshaft
- Alloy steel crosshead pins
- Bronze bearing crosshead pin bushings
- Heavy-duty, tapered roller crankshaft bearings
- Precision type, aluminum alloy crankpin bearings
- Cast iron crossheads with upper/lower oil grooves
- Stainless steel extension rods
- Internal pressure lubrication
- Bolted Type Valve Covers
- Removable Stuffing Boxes & Glands
- Plungers - Ceramic, or Tungsten Coated
