Wheatley, Q350-4 (350Q-5L), Quintuplex, Plunger Pump
- 350 horsepower 5" stroke horizontal quintuplex single acting plunger pump
- Available in three fluid end materials
- Pump speeds up to 360 RPM
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | quintuplex |
| Minimum Plunger Diameter: | 3¼" |
| Maximum Plunger Diameter: | 4" |
| Stroke length: | 5" |
| Maximum Working Pressure: | 1,670 PSI |
| Rod/Piston Load: | 19400lb |
| Gallons per Minute: | 489.6 |
| Barrels per Day: | 16790 |
| Brake Horse Power: | 350.0 |
Mouse-over to Enlarge
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 280 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| Q350-4 350Q-5L | 4.000 | 12.5664 | 46.628 | 1.3600 | 1544 | 2331 | 68.0 | 6994 | 204.0 | 11660 | 340.0 | 13060 | 380.8 |
| 3.875 | 11.7932 | 43.760 | 1.2763 | 1645 | 2188 | 63.82 | 6564 | 191.4 | 10940 | 319.1 | 12250 | 357.4 | |
| 3.750 | 11.0447 | 40.982 | 1.1953 | 1757 | 2049 | 59.77 | 6147 | 179.3 | 10250 | 298.8 | 11470 | 334.7 | |
| 3.625 | 10.3206 | 38.295 | 1.1170 | 1880 | 1915 | 55.85 | 5744 | 167.5 | 9574 | 279.2 | 10720 | 312.7 | |
| 3.500 | 9.6211 | 35.700 | 1.0412 | 2016 | 1785 | 52.06 | 5355 | 156.2 | 8925 | 260.3 | 9996 | 291.5 | |
| 3.375 | 8.9462 | 33.195 | 0.9682 | 2169 | 1660 | 48.41 | 4979 | 145.2 | 8299 | 242.1 | 9295 | 271.1 | |
| 3.250 | 8.2958 | 30.782 | 0.8978 | 2339 | 1539 | 44.89 | 4617 | 134.7 | 7696 | 224.5 | 8619 | 251.4 | |
Power End Features:
- Cast Iron Power Frame
- Forged Steel Crankshaft
- Heavy-Duty, Tapered Roller Crankshaft Bearings
- Precision type, Aluminum Alloy Crankpin Bearings
- Ductile Iron Connecting Rods
- Alloy steel crosshead pins
- Bronze bearing crosshead pin bushings
- Cast iron crossheads with upper/lower oil grooves
- Stainless steel extension rods
- External pressure lubrication
- Rated rod load is 13850 lbs.
Fluid End Features:
- Alloy steel crosshead pins
- Bronze bearing crosshead pin bushings
- Cast iron crossheads with upper/lower oil grooves
- Stainless steel extension rods
- External pressure lubrication
- Fluid end with bolted type valve covers
- Removable stuffing boxes & glands
- Plungers -Solid Ceramic, or Tungsten Coated
- General Service Plunger Packing
