Wheatley, P200-H, Triplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 1⅛" |
| Maximum Plunger Diameter: | 1" |
| Stroke length: | 2 3/16" |
| Maximum Working Pressure: | 4,600 PSI |
| Rod/Piston Load: | 2030lb |
| Gallons per Minute: | 11.5 |
| Barrels per Day: | 394 |
| Brake Horse Power: | 19.15 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 200 RPM | 350 RPM | 500 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| P200-H | 1.000 | 0.7854 | 0.765 | 0.0223 | 2585 | 38 | 1 | 153 | 4 | 268 | 8 | 382 | 11 |
