Wheatley, Q3150-MS, Quintuplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | quintuplex |
| Minimum Plunger Diameter: | 1¼" |
| Maximum Plunger Diameter: | 1¾" |
| Stroke length: | 3½" |
| Maximum Working Pressure: | 5,180 PSI |
| Rod/Piston Load: | 6350lb |
| Gallons per Minute: | 80.2 |
| Barrels per Day: | 2750 |
| Brake Horse Power: | 137.4 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 440 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| Q3150-MS | 1.750 | 2.4053 | 6.247 | 0.1822 | 2640 | 312 | 9 | 937 | 27 | 1562 | 46 | 2187 | 64 | 2749 | 80 |
| 1.625 | 2.0739 | 5.387 | 0.1571 | 3062 | 269 | 8 | 808 | 24 | 1347 | 39 | 1885 | 55 | 2370 | 69 | |
| 1.500 | 1.7671 | 4.590 | 0.1339 | 3593 | 229 | 7 | 688 | 20 | 1148 | 33 | 1607 | 47 | 2020 | 59 | |
| 1.375 | 1.4849 | 3.857 | 0.1125 | 4276 | 193 | 6 | 579 | 17 | 964 | 28 | 1350 | 39 | 1697 | 49 | |
| 1.250 | 1.2272 | 3.187 | 0.0930 | 5174 | 159 | 5 | 478 | 14 | 797 | 23 | 1116 | 33 | 1403 | 41 | |
