Wheatley, Q7600-M, Quintuplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | quintuplex |
| Minimum Plunger Diameter: | 2¼" |
| Maximum Plunger Diameter: | 3¼" |
| Stroke length: | 7⅛" |
| Maximum Working Pressure: | 4,880 PSI |
| Rod/Piston Load: | 19400lb |
| Gallons per Minute: | 358.0 |
| Barrels per Day: | 12274 |
| Brake Horse Power: | 541.0 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 280 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| Q7600-M | 3.250 | 8.2958 | 43.864 | 1.2794 | 2339 | 2193 | 64 | 6580 | 192 | 10966 | 320 | 12282 | 358 |
| 3.125 | 7.6699 | 40.555 | 1.1829 | 2529 | 2028 | 59 | 6083 | 177 | 10139 | 296 | 11355 | 331 | |
| 3.000 | 7.0686 | 37.376 | 1.0901 | 2745 | 1869 | 55 | 5606 | 164 | 9344 | 273 | 10465 | 305 | |
| 2.875 | 6.4918 | 34.326 | 1.0012 | 2988 | 1716 | 50 | 5149 | 150 | 8582 | 250 | 9611 | 280 | |
| 2.750 | 5.9396 | 31.406 | 0.9160 | 3266 | 1570 | 46 | 4711 | 137 | 7852 | 229 | 8794 | 256 | |
| 2.625 | 5.4119 | 28.616 | 0.8346 | 3585 | 1431 | 42 | 4292 | 125 | 7154 | 209 | 8012 | 234 | |
| 2.500 | 4.9087 | 25.955 | 0.7570 | 3952 | 1298 | 38 | 3893 | 114 | 6489 | 189 | 7268 | 212 | |
| 2.375 | 4.4301 | 23.425 | 0.6832 | 4379 | 1171 | 34 | 3514 | 102 | 5856 | 171 | 6559 | 191 | |
| 2.250 | 3.9761 | 21.024 | 0.6132 | 4879 | 1051 | 31 | 3154 | 92 | 5256 | 153 | 5887 | 172 | |
