Gaso, T200-3, Triplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 1¼" |
| Maximum Plunger Diameter: | 3¼" |
| Stroke length: | 5" |
| Maximum Working Pressure: | 3,020 PSI |
| Rod/Piston Load: | 13200lb |
| Gallons per Minute: | 193.9 |
| Barrels per Day: | 6648 |
| Brake Horse Power: | 200.0 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 360 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T200-3 | 3.250 | 8.2958 | 18.469 | 0.5387 | 1591 | 923 | 27 | 2770 | 81 | 4617 | 135 | 6464 | 189 | 6649 | 194 |
| 3.000 | 7.0686 | 15.737 | 0.4590 | 1867 | 787 | 23 | 2361 | 69 | 3934 | 115 | 5508 | 161 | 5665 | 165 | |
| 2.750 | 5.9396 | 13.224 | 0.3857 | 2222 | 661 | 19 | 1984 | 58 | 3306 | 96 | 4628 | 135 | 4761 | 139 | |
| 2.500 | 4.9087 | 10.929 | 0.3187 | 2689 | 546 | 16 | 1639 | 48 | 2732 | 80 | 3825 | 112 | 3934 | 115 | |
| 2.250 | 3.9761 | 8.852 | 0.2582 | 3020 | 443 | 13 | 1328 | 39 | 2213 | 65 | 3098 | 90 | 3187 | 93 | |
| 2.000 | 3.1416 | 6.994 | 0.2040 | 3020 | 350 | 10 | 1049 | 31 | 1749 | 51 | 2448 | 71 | 2518 | 73 | |
| 1.750 | 2.4053 | 5.355 | 0.1562 | 3020 | 268 | 8 | 803 | 23 | 1339 | 39 | 1874 | 55 | 1928 | 56 | |
| 1.500 | 1.7671 | 3.934 | 0.1147 | 3020 | 197 | 6 | 590 | 17 | 984 | 29 | 1377 | 40 | 1416 | 41 | |
| 1.250 | 1.2272 | 2.732 | 0.0797 | 3020 | 137 | 4 | 410 | 12 | 683 | 20 | 956 | 28 | 984 | 29 | |
