Wheatley, T600-3 (622T-8MS), Triplex, Plunger Pump
- 622 horsepower 8" stroke horizontal triplex single acting plunger pump
- Available in three fluid end materials
- Pump speeds up to 260 RPM
- Two accessory gear reduction unit ratios
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 2½" |
| Maximum Plunger Diameter: | 3" |
| Stroke length: | 8" |
| Maximum Working Pressure: | 6,170 PSI |
| Rod/Piston Load: | 35500lb |
| Gallons per Minute: | 190.9 |
| Barrels per Day: | 6545 |
| Brake Horse Power: | 622.0 |
Mouse-over to Enlarge
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 260 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T600-3 622T-8MS | 3.000 | 7.0686 | 25.179 | 0.7344 | 5022 | 1259 | 36.72 | 3777 | 110.2 | 6295 | 183.6 | 6547 | 190.9 |
| 2.875 | 6.4918 | 23.125 | 0.6745 | 5468 | 1156 | 33.72 | 3469 | 101.2 | 5781 | 168.6 | 6012 | 175.4 | |
| 2.750 | 5.9396 | 21.158 | 0.6171 | 5977 | 1058 | 30.85 | 3174 | 92.56 | 5289 | 154.3 | 5501 | 160.4 | |
| 2.625 | 5.4119 | 19.278 | 0.5623 | 6560 | 963.9 | 28.11 | 2892 | 84.34 | 4819 | 140.6 | 5012 | 146.2 | |
| 2.500 | 4.9087 | 17.486 | 0.5100 | 7232 | 874.3 | 25.5 | 2623 | 76.5 | 4371 | 127.5 | 4546 | 132.6 | |
Power End Features
- Cast iron power frame
- Forged Steel Crankshaft
- Heavy-duty, tapered roller crankshaft bearings
- Precision type, aluminum alloy crankpin bearings
- Ductile iron connecting rods
- Alloy steel crosshead pins
- Bronze bearing crosshead pin bushings
- Cast iron crossheads with upper/lower oil grooves
- Stainless Steel Extension Rods
- Pressure lubricated power end
- Rated rod load is 35500 lbs.
Fluid End Features
- Bolted Type Valve Covers
- Removable Stuffing Boxes & Glands
- Plungers - Solid Ceramic, or Tungsten Coated
- General service plunger packing
