Wheatley, T600-5 (622T-8L), Triplex, Plunger Pump
- 622 horsepower 8" stroke horizontal triplex single acting plunger pump
- Available in three fluid end materials
- Pump speeds up to 260 RPM
- Two accessory gear reduction unit ratios
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 4¼" |
| Maximum Plunger Diameter: | 5" |
| Stroke length: | 8" |
| Maximum Working Pressure: | 2,220 PSI |
| Rod/Piston Load: | 35500lb |
| Gallons per Minute: | 530.4 |
| Barrels per Day: | 18190 |
| Brake Horse Power: | 622.0 |
Mouse-over to Enlarge
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 260 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T600-5 622T-8L | 5.000 | 19.6350 | 69.943 | 2.0400 | 1808 | 3497 | 102.0 | 10490 | 306.0 | 17490 | 510.0 | 18190 | 530.4 |
| 4.875 | 18.6655 | 66.489 | 1.9393 | 1902 | 3324 | 96.96 | 9973 | 290.9 | 16620 | 484.8 | 17290 | 504.2 | |
| 4.750 | 17.7205 | 63.123 | 1.8411 | 2003 | 3156 | 92.05 | 9468 | 276.2 | 15780 | 460.3 | 16410 | 478.7 | |
| 4.625 | 16.8002 | 59.845 | 1.7455 | 2113 | 2992 | 87.27 | 8977 | 261.8 | 14960 | 436.4 | 15560 | 453.8 | |
| 4.500 | 15.9043 | 56.654 | 1.6524 | 2232 | 2833 | 82.62 | 8498 | 247.9 | 14160 | 413.1 | 14730 | 429.6 | |
| 4.375 | 15.0330 | 53.550 | 1.5619 | 2361 | 2677 | 78.09 | 8032 | 234.3 | 13390 | 390.5 | 13920 | 406.1 | |
| 4.250 | 14.1863 | 50.534 | 1.4739 | 2502 | 2527 | 73.69 | 7580 | 221.1 | 12630 | 368.5 | 13140 | 383.2 | |
Power End Features
- Cast iron power frame
- Forged Steel Crankshaft
- Heavy-duty, tapered roller crankshaft bearings
- Precision type, aluminum alloy crankpin bearings
- Ductile iron connecting rods
- Alloy steel crosshead pins
- Bronze bearing crosshead pin bushings
- Cast iron crossheads with upper/lower oil grooves
- Stainless Steel Extension Rods
- Pressure lubricated power end
- Rated rod load is 35500 lbs.
Fluid End Features
- Bolted Type Valve Covers
- Removable Stuffing Boxes & Glands
- Plungers - Solid Ceramic, or Tungsten Coated
- General service plunger packing
