Wheatley, HP200-AL (217Q-4L), Quintuplex, Plunger Pump

  • 217 horsepower 4 1/2" stroke horizontal quintuplex single acting plunger pump
  • Available in three end materials
  • Pump speeds up to 390 RPM
  • Multiple accessory gear reduction unit ratios

Specs

Spec U.S. Standard
Type: quintuplex
Minimum Plunger Diameter: 2⅝"
Maximum Plunger Diameter: 3⅜"
Stroke length: 4½"
Maximum Working Pressure: 1,440 PSI
Rod/Piston Load: 6600lb
Gallons per Minute: 339.8
Barrels per Day: 11650
Brake Horse Power: 217.0

HP200-AL (217Q-4L), Quintuplex, Plunger Pump
Mouse-over to Enlarge HP200-AL (217Q-4L), Quintuplex, Plunger Pump

Hover over Power Curves to reveal RPM and GPM

PumpEnglish Units50 RPM150 RPM250 RPM350 RPM390 RPM
Plunger Dia. In.Plunger Area Sq. In.BPD per RPMGPM per RPMMax Press. PSIBPDGPMBPDGPMBPDGPMBPDGPMBPDGPM
HP200-AL
217Q-4L
3.3758.946229.8760.8714738149444448113174692181045730511652340
3.2508.295827.7040.808079613854041561216926202969628310805315
3.1257.669925.6140.74718611281373842112640318789652619989291
3.0007.068623.6060.68859341180343541103590117282622419206269
2.8756.491821.6800.63231017108432325295542015875882218455247
2.7505.939619.8350.5785111199229297587495914569422027736226
2.6255.411918.0730.5271122090426271179451813263261847049206
  • Cast iron power frame
  • Ductile Iron Crankshaft
  • Heavy-duty, Tapered Roller Crankshaft Bearings
  • Precision Type, Aluminum Alloy Crankpin Bearings
  • Stainless Steel Extension Rods
  • Internal Pressure Lubrication
  • Ductile Iron Connecting Rods
  • Alloy Steel Crosshead Pins
  • Bronze Bearing Crosshead Pin Bushings
  • Cast Iron Crossheads with upper/lower oil grooves
  • Rated Rod Load is 8800 lbs.
  • Bolted Valve Covers
  • Integral Stuffing Boxes & Glands Â
