Wheatley, HP125-M, Quintuplex, Plunger Pump

Specs

Spec U.S. Standard
Type: quintuplex
Minimum Plunger Diameter: 1¾"
Maximum Plunger Diameter: 3"
Stroke length: 3½"
Maximum Working Pressure: 2,115 PSI
Rod/Piston Load: 5090lb
Gallons per Minute: 163.7
Barrels per Day: 5613
Brake Horse Power: 110.0

Pump, HP125-M
Mouse-over to Enlarge Pump, HP125-M

PumpEnglish Units50 RPM150 RPM250 RPM350 RPM440 RPM
Plunger Dia. In.Plunger Area Sq. In.BPD per RPMGPM per RPMMax Press. PSIBPDGPMBPDGPMBPDGPMBPDGPMBPDGPM
HP125-M
3.0007.068618.3600.5355720918.026.77275480.324590133.96426187.48078235.6
2.8756.491816.8620.4918784843.124.59252973.774215123.05902172.17419216.4
2.7505.939615.4270.4500857771.422.5231467.53857112.55400157.56788198.0
2.6255.411914.0570.4100941702.820.5210961.53514102.54920143.56185180.4
2.5004.908712.7500.37191037637.518.59191255.78318792.974462130.25610163.6
2.3754.430111.5070.33561149575.316.78172650.34287783.94027117.55063147.7
2.2503.976110.3270.30121280516.415.06154945.18258275.33615105.44544132.5
2.1253.54669.2120.26871435460.613.43138240.3230367.17322494.044053118.2
2.0003.14168.1600.23801620408.011.9122435.7204059.5285683.33590104.7
1.8752.76127.1720.20921843358.610.46107631.38179352.29251073.21315692.04
1.7502.40536.2470.18222116312.49.111937.127.33156245.55218763.78274980.18
  • Cast iron power frame
  • Ductile Iron Crankshaft
  • Heavy-duty, tapered roller crankshaft bearings
  • Precision type, aluminum alloy crankpin bearings
  • Cast iron crossheads with upper/lower oil grooves
  • Internal pressure lubrication
  • Ductile iron connecting rods
  • Alloy steel crosshead pins
  • Bronze bearing crosshead pin bushings
  • Rated rod load is 5090 lbs.
  • Plungers - Solid Ceramic, or Tungsten coated¬†¬†
