Wheatley, HP250-H, Triplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 1⅜" |
| Maximum Plunger Diameter: | 1⅞" |
| Stroke length: | 7⅛" |
| Maximum Working Pressure: | 7,800 PSI |
| Rod/Piston Load: | 11580lb |
| Gallons per Minute: | 67.7 |
| Barrels per Day: | 2321 |
| Brake Horse Power: | 189.0 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 265 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| HP250-H | 1.875 | 2.7612 | 8.760 | 0.2555 | 4194 | 438 | 13 | 1314 | 38 | 2190 | 64 | 2321 | 68 |
| 1.750 | 2.4053 | 7.631 | 0.2226 | 4814 | 382 | 11 | 1145 | 33 | 1908 | 56 | 2022 | 59 | |
| 1.625 | 2.0739 | 6.580 | 0.1919 | 5584 | 329 | 10 | 987 | 29 | 1645 | 48 | 1744 | 51 | |
| 1.500 | 1.7671 | 5.606 | 0.1635 | 6553 | 280 | 8 | 841 | 25 | 1402 | 41 | 1486 | 43 | |
| 1.375 | 1.4849 | 4.711 | 0.1374 | 7799 | 236 | 7 | 707 | 21 | 1178 | 34 | 1248 | 36 | |
