Wheatley, P50-BH (2S-1H), Simplex, Plunger Pump
Pumps in this series
P50-A (5S-2M)P50-ALS (5S-2L)
P50-B (2S-1M)
P50-BH (2S-1H)
P50-BLS (2S-1L)
P50-H (5S-2H)
- 2 ½ horsepower 1" stroke horizontal simplex single acting plunger pump
- Available in four different fluid end materials
- Pump speeds up to 350 RPM
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | simplex |
| Minimum Plunger Diameter: | ¾" |
| Maximum Plunger Diameter: | 1" |
| Stroke length: | 1" |
| Maximum Working Pressure: | 4,595 PSI |
| Rod/Piston Load: | 2030lb |
| Gallons per Minute: | 1.2 |
| Barrels per Day: | 41 |
| Brake Horse Power: | 2.5 |
Mouse-over to Enlarge
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| P50-BH 2S-1H | 1.000 | 0.7854 | 0.117 | 0.0034 | 2585 | 6 | 0 | 17 | 1 | 29 | 1 | 41 | 1 |
| 0.875 | 0.6013 | 0.089 | 0.0026 | 3376 | 4 | 0 | 13 | 0 | 22 | 1 | 31 | 1 | |
| 0.750 | 0.4418 | 0.066 | 0.0019 | 4595 | 3 | 0 | 10 | 0 | 16 | 0 | 23 | 1 | |
Power End Features
- Cast iron power frame
- Heavy-duty roller crankshaft bearings
- Precision type, aluminum alloy crankpin bearings
- Cast iron connecting rods
- Alloy steel crosshead pins
- Ductile iron crankshaft with ground journals & polished throws
- Bronze bearing crosshead pin bushings
- Cast iron crossheads with upper/lower oil grooves
- Flooded sump, splash distribution lubrication
- Rated rod load is 2030 lbs.
Fluid End Features
- Threaded valve covers
- Bolted valve covers on PSTL and forged fluid ends
- Threaded type glands & integral stuffing boxes
- Bronze stuffing box bushings and packing followers
- Plungers - solid ceramic, or tungsten coated
- General service plunger packing
- Spherical suction and discharge valves
- Valve seat & valve body: Nitronic 50
- Spring: inconel
- Cage: 316L Stainless Steel
- Cage: 316L Stainless Steel
- Threaded suction and discharge connectionsÂ
