Wheatley, P50-H (5S-2H), Simplex, Plunger Pump
Pumps in this series
P50-A (5S-2M)P50-ALS (5S-2L)
P50-B (2S-1M)
P50-BH (2S-1H)
P50-BLS (2S-1L)
P50-H (5S-2H)
- 5 horsepower 2.188" stroke horizontal simplex single acting plunger pump
- Available in four different fluid end materials
- Pump speeds up to 350 RPM
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | simplex |
| Minimum Plunger Diameter: | ¾" |
| Maximum Plunger Diameter: | 1" |
| Stroke length: | 2 3/16" |
| Maximum Working Pressure: | 4,595 PSI |
| Rod/Piston Load: | 2030lb |
| Gallons per Minute: | 2.6 |
| Barrels per Day: | 89 |
| Brake Horse Power: | 5.5 |
Mouse-over to Enlarge
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 200 RPM | 350 RPM | 500 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| P50-H 5S-2H | 1.000 | 0.7854 | 0.255 | 0.0074 | 2585 | 13 | 0 | 51 | 1 | 89 | 3 | 127 | 4 |
| 0.875 | 0.6013 | 0.195 | 0.0057 | 3376 | 10 | 0 | 39 | 1 | 68 | 2 | 98 | 3 | |
| 0.750 | 0.4418 | 0.143 | 0.0042 | 4595 | 7 | 0 | 29 | 1 | 50 | 1 | 72 | 2 | |
Power End Features:
- Cast iron power frame
- Alloy steel crosshead pins
- Heavy-duty roller crankshaft bearings
- Precision type, aluminum alloy crankpin bearings
- Cast iron connecting rods
- Ductile Iron crankshaft with ground journals & polished throws
- Bronze bearing crosshead pin bushings
- Cast iron crossheads with upper/lower oil grooves
- One piece plungers
- Flooded sump, splash distribution lubrication
- Rated rod load is 2030 lbs
Fluid End Features:
- Bolted Covers forged Liquid Ends
- Threaded type glands & integral stuffing boxes
- Bronze stuffing box bushings and packing followers
- Optional flanged connections available
- Abrasion Resistant Valves
- Plungers - Solid Ceramic, or Tungsten Coated
- Spring loaded Plunger PackingÂ
