Gaso, T140-2 (133T-4H), Triplex, Plunger Pump

  • 133 horsepower 4 1/2" stroke horizontal triplex single acting plunger pump
  • Available in three fluid end materials
  • Pump speeds up to 400 RPM
  • Multiple gear reduction unit ratios

Specs

Spec U.S. Standard
Type: triplex
Minimum Plunger Diameter: 1¼"
Maximum Plunger Diameter: 1⅝"
Stroke length: 4½"
Maximum Working Pressure: 6,000 PSI
Rod/Piston Load: 8800lb
Gallons per Minute: 48.5
Barrels per Day: 1663
Brake Horse Power: 133.0

T140-2 (133T-4H), Triplex, Plunger Pump
Mouse-over to Enlarge T140-2 (133T-4H), Triplex, Plunger Pump

Hover over Power Curves to reveal RPM and GPM

PumpEnglish Units50 RPM150 RPM250 RPM350 RPM400 RPM
Plunger Dia. In.Plunger Area Sq. In.BPD per RPMGPM per RPMMax Press. PSIBPDGPMBPDGPMBPDGPMBPDGPMBPDGPM
T140-2
133T-4H
1.6252.07394.1560.12124243208662318103930145542166248
1.5001.76713.5410.1033498017755311588526123936141641
1.3751.48492.9750.0868592614944461374422104130119035
1.2501.22722.4590.07176000123436911615188612598429
  • Cast iron power frame
  • Forged Steel Crankshaft
  • Heavy-duty, tapered roller crankshaft bearings
  • Precision type, aluminum alloy crankpin bearings
  • Ductile iron connecting rods
  • Minimum pump speed is 150 with standard power end construction
  • Bronze bearing crosshead pin bushings
  • Cast iron crossheads with upper/lower oil grooves
  • Stainless steel extension rods
  • Internal pressure lubrication
  • Alloy steel crosshead pins
  • Rated rod load is 8800 lbs.
  • Plungers - Solid Ceramic, or Tungsten coated
  • Spherical suction and discharge valves
  • Valve Seat & Valve Body: Nitronic 50
  • Spring: Inconel
  • Cage: 316L Stainless Steel
  • Severe duty valves with inserts available
