Wheatley, T365-H (59T-3H), Triplex, Plunger Pump
- 59 horsepower 3 1/2" stroke horizontal triplex single acting plunger pump
- Available in four different fluid end materials
- Pump speeds up to 420 RPM
- Multiple accessory gear reduction unit ratios
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | ¾" |
| Maximum Plunger Diameter: | 1" |
| Stroke length: | 3½" |
| Maximum Working Pressure: | 10,000 PSI |
| Rod/Piston Load: | 4760lb |
| Gallons per Minute: | 14.99 |
| Barrels per Day: | 514 |
| Brake Horse Power: | 59.0 |
Mouse-over to Enlarge
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 420 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T365-H 59T-3H | 1.000 | 0.7854 | 1.224 | 0.0357 | 6061 | 61.2 | 1.785 | 183.6 | 5.355 | 306.0 | 8.925 | 428.4 | 12.49 | 514.1 | 14.99 |
| 0.875 | 0.6013 | 0.937 | 0.0273 | 7916 | 46.86 | 1.367 | 140.6 | 4.1 | 234.3 | 6.833 | 328.0 | 9.566 | 393.6 | 11.48 | |
| 0.750 | 0.4418 | 0.688 | 0.0201 | 10774 | 34.42 | 1.004 | 103.3 | 3.012 | 172.1 | 5.02 | 241.0 | 7.028 | 289.2 | 8.434 | |
- Cast iron power frame
- Ductile Iron Crankshaft
- Heavy-duty roller crankshaft bearings
- Bi-Metal crankpin bearings
- Alloy steel crosshead pins
- Bronze bearing crosshead pin bushings
- Cast iron crossheads with upper/lower oil grooves
