Wheatley, T365-AM (59T-3M), Triplex, Plunger Pump
- 59 horsepower 3 1/2" stroke horizontal triplex single acting plunger pump
- Available in four different fluid end materials
- Pump speeds up to 420 RPM
- Multiple accessory gear reduction unit ratios
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 1⅝" |
| Maximum Plunger Diameter: | 2½" |
| Stroke length: | 3½" |
| Maximum Working Pressure: | 2,295 PSI |
| Rod/Piston Load: | 4760lb |
| Gallons per Minute: | 93.71 |
| Barrels per Day: | 3213 |
| Brake Horse Power: | 59.0 |
Mouse-over to Enlarge
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 350 RPM | 420 RPM | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T365-AM 59T-3M | 2.500 | 4.9087 | 7.650 | 0.2231 | 970 | 382.5 | 11.16 | 1147 | 33.47 | 1912 | 55.78 | 2677 | 78.09 | 3213 | 93.71 |
| 2.375 | 4.4301 | 6.904 | 0.2014 | 1074 | 345.2 | 10.07 | 1036 | 30.21 | 1726 | 50.34 | 2416 | 70.48 | 2900 | 84.58 | |
| 2.250 | 3.9761 | 6.196 | 0.1807 | 1197 | 309.8 | 9.037 | 929.5 | 27.11 | 1549 | 45.18 | 2169 | 63.26 | 2603 | 75.91 | |
| 2.125 | 3.5466 | 5.527 | 0.1612 | 1342 | 276.4 | 8.06 | 829.1 | 24.18 | 1382 | 40.3 | 1934 | 56.42 | 2321 | 67.71 | |
| 2.000 | 3.1416 | 4.896 | 0.1428 | 1515 | 244.8 | 7.14 | 734.4 | 21.42 | 1224 | 35.7 | 1714 | 49.98 | 2056 | 59.98 | |
| 1.875 | 2.7612 | 4.303 | 0.1255 | 1724 | 215.2 | 6.275 | 645.5 | 18.83 | 1076 | 31.38 | 1506 | 43.93 | 1807 | 52.71 | |
| 1.750 | 2.4053 | 3.748 | 0.1093 | 1979 | 187.4 | 5.467 | 562.3 | 16.4 | 937.1 | 27.33 | 1312 | 38.27 | 1574 | 45.92 | |
| 1.625 | 2.0739 | 3.232 | 0.0943 | 2295 | 161.6 | 4.714 | 484.8 | 14.14 | 808.0 | 23.57 | 1131 | 32.99 | 1357 | 39.59 | |
- Cast iron power frame
- Ductile Iron Crankshaft
- Heavy-duty roller crankshaft bearings
- Bi-Metal crankpin bearings
- Alloy steel crosshead pins
- Bronze bearing crosshead pin bushings
- Cast iron crossheads with upper/lower oil grooves
