Gaso, T450-3, Triplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 2½" |
| Maximum Plunger Diameter: | 3" |
| Stroke length: | 8" |
| Maximum Working Pressure: | 5,000 PSI |
| Rod/Piston Load: | 26000lb |
| Gallons per Minute: | 191.0 |
| Barrels per Day: | 6549 |
| Brake Horse Power: | 455.0 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 260 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T450-3 | 3.000 | 7.0686 | 25.179 | 0.7344 | 3678 | 1259 | 37 | 3777 | 110 | 6295 | 184 | 6547 | 191 |
| 2.875 | 6.4918 | 23.125 | 0.6745 | 4005 | 1156 | 34 | 3469 | 101 | 5781 | 169 | 6012 | 175 | |
| 2.750 | 5.9396 | 21.158 | 0.6171 | 4377 | 1058 | 31 | 3174 | 93 | 5289 | 154 | 5501 | 160 | |
| 2.625 | 5.4119 | 19.278 | 0.5623 | 4804 | 964 | 28 | 2892 | 84 | 4820 | 141 | 5012 | 146 | |
| 2.500 | 4.9087 | 17.486 | 0.5100 | 5000 | 874 | 25 | 2623 | 76 | 4371 | 127 | 4546 | 133 | |
