Gaso, T450-5, Triplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 4¼" |
| Maximum Plunger Diameter: | 5" |
| Stroke length: | 8" |
| Maximum Working Pressure: | 1,830 PSI |
| Rod/Piston Load: | 26000lb |
| Gallons per Minute: | 530.0 |
| Barrels per Day: | 18171 |
| Brake Horse Power: | 455.0 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 260 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T450-5 | 5.000 | 19.6350 | 69.943 | 2.0400 | 1324 | 3497 | 102 | 10491 | 306 | 17486 | 510 | 18185 | 530 |
| 4.875 | 18.6655 | 66.489 | 1.9393 | 1393 | 3325 | 97 | 9973 | 291 | 16622 | 485 | 17287 | 504 | |
| 4.750 | 17.7205 | 63.123 | 1.8411 | 1467 | 3156 | 92 | 9469 | 276 | 15781 | 460 | 16412 | 479 | |
| 4.625 | 16.8002 | 59.845 | 1.7455 | 1548 | 2992 | 87 | 8977 | 262 | 14961 | 436 | 15560 | 454 | |
| 4.500 | 15.9043 | 56.654 | 1.6524 | 1635 | 2833 | 83 | 8498 | 248 | 14163 | 413 | 14730 | 430 | |
| 4.375 | 15.0330 | 53.550 | 1.5619 | 1730 | 2678 | 78 | 8033 | 234 | 13387 | 390 | 13923 | 406 | |
| 4.250 | 14.1863 | 50.534 | 1.4739 | 1830 | 2527 | 74 | 7580 | 221 | 12633 | 368 | 13139 | 383 | |
