Gaso, T450-7, Triplex, Plunger Pump
Specs
| Spec | U.S. Standard |
|---|---|
| Type: | triplex |
| Minimum Plunger Diameter: | 5¼" |
| Maximum Plunger Diameter: | 7" |
| Stroke length: | 8" |
| Maximum Working Pressure: | 1,200 PSI |
| Rod/Piston Load: | 26000lb |
| Gallons per Minute: | 1040.0 |
| Barrels per Day: | 35657 |
| Brake Horse Power: | 455.0 |
Mouse-over to Enlarge
- Pump Curves
- Performance Data Table
- Features/benefits not available.
Hover over Power Curves to reveal RPM and GPM
| Pump | English Units | 50 RPM | 150 RPM | 250 RPM | 260 RPM | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
| T450-7 | 7.000 | 38.4845 | 137.088 | 3.9984 | 676 | 6854 | 200 | 20563 | 600 | 34272 | 1000 | 35643 | 1040 |
| 6.750 | 35.7847 | 127.471 | 3.7179 | 727 | 6374 | 186 | 19121 | 558 | 31868 | 929 | 33142 | 967 | |
| 6.500 | 33.1831 | 118.203 | 3.4476 | 784 | 5910 | 172 | 17730 | 517 | 29551 | 862 | 30733 | 896 | |
| 6.250 | 30.6796 | 109.285 | 3.1875 | 847 | 5464 | 159 | 16393 | 478 | 27321 | 797 | 28414 | 829 | |
| 6.000 | 28.2743 | 100.717 | 2.9376 | 920 | 5036 | 147 | 15108 | 441 | 25179 | 734 | 26187 | 764 | |
| 5.750 | 25.9672 | 92.499 | 2.6979 | 1001 | 4625 | 135 | 13875 | 405 | 23125 | 674 | 24050 | 701 | |
| 5.500 | 23.7583 | 84.631 | 2.4684 | 1094 | 4232 | 123 | 12695 | 370 | 21158 | 617 | 22004 | 642 | |
| 5.250 | 21.6475 | 77.112 | 2.2491 | 1200 | 3856 | 112 | 11567 | 337 | 19278 | 562 | 20049 | 585 | |
